Bosch Series 4, Gas Hob, 90 cm, Tempered Glass, Black PNF9B6G20I

Product name/family: ………………………gas hob w integrated controls
Built-in / Free-standing: …………………………………………………..Built-in
Energy input: ………………………………………………………………………Gas
Total number of positions that can be used at the same time: ……… 4
Type of control setting devices: ……………………………….. sword knobs
Min. required niche size for installation (HxWxD): ……45 x 850-852 x
490-502 mm
Width of the appliance: ………………………………………………….915 mm
Dimensions: …………………………………………………. 56 x 915 x 520 mm
Dimensions of the packed product (HxWxD): … 165 x 1116 x 659 mm
Net weight: ……………………………………………………………………20.2 kg
Gross weight: ……………………………………………………………….. 22.4 kg
Residual heat indicator: …………………………………………………. without
Location of control panel: …………………………………………….Hob front
Basic surface material: ……………………………………….. Tempered glass
Color of surface: ……………………………………………………………….Black
Color of frame: …………………………………………………………………Black
Length electrical supply cord: ……………………………………….150.0 cm
Knob Material: ………………………………………………………………..Plastic
Sealed Burners: ……………………………………………………………………No
Power of heating element (kW): …………………………………………..4 kW
Power of 3rd heating element (kW): …………………………………. 2.3 kW
Power of 5th heating element (kW): …………………………………. 1.7 kW
Connection rating: ……………………………………………………………… 1 W
Gas connection rating: ………………………………………………….12000 W
Fuse protection: …………………………………………………………………..3 A
Voltage: ……………………………………………………………………. 220-240 V
Frequency: ……………………………………………………………………… 50 Hz
Energy input: ………………………………………………………………………Gas
Gas type: …………………………………..Liquidgas G30,31 28-30/37 mbar
Alternative gas type: ……………………….. Nat gas H/E/(L) 20 (25) mbar
Plug type: ………………………………………………… India plug (6 Ampere)
Appliance Dimensions (h x w x d) (in): …………………………………… x x
Dimensions of the packed product: ……………….. 6.49 x 25.94 x 43.93
Net weight: ……………………………………………………………….45.000 lbs
Gross weight: …………………………………………………………… 49.000 lbs
Total number of positions that can be used at the same time: ……… 4
Length electrical supply cord: ……………………………………….150.0 cm
Min. required niche size for installation (HxWxD): ……45 x 850-852 x
490-502 mm
Dimensions: …………………………………………………. 56 x 915 x 520 mm
Dimensions of the packed product (HxWxD): … 165 x 1116 x 659 mm
Net weight: ……………………………………………………………………20.2 kg
Gross weight: ……………………………………………………………….. 22.4 kg
